Stage BlinderSKU: AI-VORTEX-FLASH-400In Production
AI VORTEX FLASH - 400 Multi-Zone Strobe & Stage Blinder
400W high-speed multi-zone LED strobe and wash bar with 864 RGB tri-color LEDs and 96 high-intensity white strobe LEDs, 8+8 zone macro effects, and 1–30Hz pulse strobe.
Key Highlights
Light Source864 x 5050 RGB Tri-Color LEDs + 96 x High-Intensity White Strobe LEDs
Rated Power400W High-Performance Version
Input VoltageAC 100V-240V, 50/60Hz
Dimming Resolution32-Bit 0–100% Linear Dimming
Strobe Rate1–30 Hz Variable Speed & Pulse Strobe
Zone Control8 Independent RGB Zones + 8 Independent White Strobe Segments
📞
Chat on WhatsApp›Factory Helpline+91 90150 60000
COMMERCIAL PROCUREMENT
Factory DirectRequest Official Quotation
ENGINEERING DATASHEET
Technical Specifications & Parameters
Full electrical, optical, thermal, and photometric characteristics for lighting designers, venue consultants, and electrical contractors.
| Parameter / Specification | Technical Value / Rating |
|---|---|
| Light Source | 864 x 5050 RGB Tri-Color LEDs + 96 x High-Intensity White Strobe LEDs |
| Rated Power | 400W High-Performance Version |
| Input Voltage | AC 100V-240V, 50/60Hz |
| Dimming Resolution | 32-Bit 0–100% Linear Dimming |
| Strobe Rate | 1–30 Hz Variable Speed & Pulse Strobe |
| Zone Control | 8 Independent RGB Zones + 8 Independent White Strobe Segments |
| Control Modes | DMX512, RDM, Auto-Run, Master/Slave, Sound Active |
| DMX Channels | CH04, CH11, CH32, CH39 Selectable |
| Operating Temperature | -30°C to +50°C |
| Housing | Heavy-Duty Metal Alloy, Anti-Glare Black Finish |
| Protection Rating | IP20 |
| Net Weight | 7.5 kg |
CE & RoHS Certified
Complies with international electrical safety, harmonic suppression, and environmental standards.
Universal DMX512-A
Standard 3-pin / 5-pin XLR connectors, Art-Net/sACN compatible, with optoisolated data inputs.
Rigging & Flightcase
Supplied with safety wire loops, Omega quick-lock clamps, and touring-grade dual road cases on request.
Pan-India Support
Spare parts stock (ballasts, LED chips, power supplies, stepper motors) maintained across 20+ hubs.
