Profile SpotlightSKU: AI-RAY-PS300ZIn Production
AI RAY - PS 300/Z Manual Zoom 300W COB Profile Spotlight
Variable zoom 300W COB LED profile spotlight offering smooth optical zoom adjustment (19°–36°), framing shutter system, and studio-grade 3200K/5600K output.
Key Highlights
Light Source300W COB LED Module
Rated Power300W
Input VoltageAC 110V-240V, 50/60Hz
Optical Zoom Angle19° to 36° Continuous Manual Zoom
Color Temperature3200K / 5600K Dual Option
Color Rendering Index (CRI)Ra ≥ 95
📞
Chat on WhatsApp›Factory Helpline+91 90150 60000
COMMERCIAL PROCUREMENT
Factory DirectRequest Official Quotation
ENGINEERING DATASHEET
Technical Specifications & Parameters
Full electrical, optical, thermal, and photometric characteristics for lighting designers, venue consultants, and electrical contractors.
| Parameter / Specification | Technical Value / Rating |
|---|---|
| Light Source | 300W COB LED Module |
| Rated Power | 300W |
| Input Voltage | AC 110V-240V, 50/60Hz |
| Optical Zoom Angle | 19° to 36° Continuous Manual Zoom |
| Color Temperature | 3200K / 5600K Dual Option |
| Color Rendering Index (CRI) | Ra ≥ 95 |
| Framing Shutters | 4-Blade Internal Stainless Steel Masking Assembly |
| Dimming & Strobe | 0–100% 16-Bit Linear Dimming, 1–25 fps Strobe |
| Control Modes | DMX512 (2CH / 3CH) & Manual Potentiometer |
| Display Panel | High-Contrast LCD Display |
| Housing | Die-Cast Aluminum & Cold-Rolled Steel |
| Protection Rating | IP20 |
| Dimensions (L x W x H) | 610 x 175 x 215 mm |
| Net Weight | 9.0 kg |
CE & RoHS Certified
Complies with international electrical safety, harmonic suppression, and environmental standards.
Universal DMX512-A
Standard 3-pin / 5-pin XLR connectors, Art-Net/sACN compatible, with optoisolated data inputs.
Rigging & Flightcase
Supplied with safety wire loops, Omega quick-lock clamps, and touring-grade dual road cases on request.
Pan-India Support
Spare parts stock (ballasts, LED chips, power supplies, stepper motors) maintained across 20+ hubs.
