Profile SpotlightSKU: AI-RAY-PS300FFIn Production
AI RAY - PS 300/FF Fixed Focus 300W COB Profile Spotlight
Precision 300W COB LED ellipsoidal profile spot fixture featuring interchangeable fixed lenses (19°/26°/36°), razor-sharp 4-blade framing shutters, and high CRI Ra ≥ 95.
Key Highlights
Light Source300W COB LED Engine (50,000 hrs lifespan)
Rated Power300W
Input VoltageAC 110V-240V, 50/60Hz
Lens Options (Fixed Focus)Interchangeable 19° / 26° / 36° High-Precision Optical Lens
Color Temperature3200K (Warm White) / 5600K (Cool White)
Color Rendering Index (CRI)Ra ≥ 95
📞
Chat on WhatsApp›Factory Helpline+91 90150 60000
COMMERCIAL PROCUREMENT
Factory DirectRequest Official Quotation
ENGINEERING DATASHEET
Technical Specifications & Parameters
Full electrical, optical, thermal, and photometric characteristics for lighting designers, venue consultants, and electrical contractors.
| Parameter / Specification | Technical Value / Rating |
|---|---|
| Light Source | 300W COB LED Engine (50,000 hrs lifespan) |
| Rated Power | 300W |
| Input Voltage | AC 110V-240V, 50/60Hz |
| Lens Options (Fixed Focus) | Interchangeable 19° / 26° / 36° High-Precision Optical Lens |
| Color Temperature | 3200K (Warm White) / 5600K (Cool White) |
| Color Rendering Index (CRI) | Ra ≥ 95 |
| Framing System | 4 Manual Stainless Steel Shutter Blades |
| Gobo Slot | Standard Size B Metal / Glass Gobo Holder |
| Dimming | 0–100% Linear Dimming Curve |
| Control Protocol | DMX512 (2CH / 3CH) & Manual Control |
| Display Panel | Backlit LCD Screen |
| Protection Rating | IP20 |
| Dimensions (L x W x H) | 640 x 175 x 215 mm |
| Net Weight | 9.5 kg |
CE & RoHS Certified
Complies with international electrical safety, harmonic suppression, and environmental standards.
Universal DMX512-A
Standard 3-pin / 5-pin XLR connectors, Art-Net/sACN compatible, with optoisolated data inputs.
Rigging & Flightcase
Supplied with safety wire loops, Omega quick-lock clamps, and touring-grade dual road cases on request.
Pan-India Support
Spare parts stock (ballasts, LED chips, power supplies, stepper motors) maintained across 20+ hubs.
