Profile SpotlightSKU: AI-PERFORMER-FS300EZIn Production
AI PERFORMER - FS 300 EZ 300W Motorized Electronic Zoom Fresnel Spotlight
Broadcast and theatrical 300W COB LED Fresnel spotlight equipped with remote DMX motorized electronic zoom (15°–50°), studio-grade CRI Ra ≥ 95, 3200K/5600K dual temperature, and rotatable 8-leaf barndoor.
Key Highlights
Light Source300W High-Power COB LED Module
Total Power Consumption300W
Input VoltageAC 110V–240V, 50/60Hz
Color Temperature3200K Warm White / 5600K Cool White
Color Rendering Index (CRI)Ra ≥ 95
Motorized Zoom Range15° to 50° Electronic Zoom
📞
Chat on WhatsApp›Factory Helpline+91 90150 60000
COMMERCIAL PROCUREMENT
Factory DirectRequest Official Quotation
ENGINEERING DATASHEET
Technical Specifications & Parameters
Full electrical, optical, thermal, and photometric characteristics for lighting designers, venue consultants, and electrical contractors.
| Parameter / Specification | Technical Value / Rating |
|---|---|
| Light Source | 300W High-Power COB LED Module |
| Total Power Consumption | 300W |
| Input Voltage | AC 110V–240V, 50/60Hz |
| Color Temperature | 3200K Warm White / 5600K Cool White |
| Color Rendering Index (CRI) | Ra ≥ 95 |
| Motorized Zoom Range | 15° to 50° Electronic Zoom |
| Lens Type | Optical Borosilicate Glass Fresnel Lens |
| Control Modes | DMX512 (Monochrome 3CH / Dual-Temperature 5CH), Manual |
| Dimming Curve | 16-bit Smooth Linear 0–100% Dimming |
| Barndoor | Heavy-Duty Rotatable 4-Leaf Metal Barndoor Included |
| Lifespan | 50,000 Hours |
| Display | Digital LCD Display Panel |
| Dimensions (L x W x H) | 390 x 180 x 220 mm |
| Net Weight | 7 kg |
| Ingress Protection | IP20 |
CE & RoHS Certified
Complies with international electrical safety, harmonic suppression, and environmental standards.
Universal DMX512-A
Standard 3-pin / 5-pin XLR connectors, Art-Net/sACN compatible, with optoisolated data inputs.
Rigging & Flightcase
Supplied with safety wire loops, Omega quick-lock clamps, and touring-grade dual road cases on request.
Pan-India Support
Spare parts stock (ballasts, LED chips, power supplies, stepper motors) maintained across 20+ hubs.
