Profile SpotlightSKU: AI-NOVA-FS600In Production
AI NOVA - FS 600 High-Power 600W LED Follow Spot
Long-throw 600W OSRAM LED follow spot with 150-meter effective projection distance, adjustable color temperatures (3200K / 5600K / 8500K), CRI ≥ 90, and heavy-duty tripod stand.
Key Highlights
Light Source600W OSRAM High-Power LED Film Module (50,000 hrs lifespan)
Total Power Consumption650W
Input VoltageAC 110V-220V, 50/60Hz
Projection DistanceUp to 150 meters
Beam Angle6°–15° Linear Zoom
Color Temperatures3200K / 5600K / 8500K Adjustable
📞
Chat on WhatsApp›Factory Helpline+91 90150 60000
COMMERCIAL PROCUREMENT
Factory DirectRequest Official Quotation
ENGINEERING DATASHEET
Technical Specifications & Parameters
Full electrical, optical, thermal, and photometric characteristics for lighting designers, venue consultants, and electrical contractors.
| Parameter / Specification | Technical Value / Rating |
|---|---|
| Light Source | 600W OSRAM High-Power LED Film Module (50,000 hrs lifespan) |
| Total Power Consumption | 650W |
| Input Voltage | AC 110V-220V, 50/60Hz |
| Projection Distance | Up to 150 meters |
| Beam Angle | 6°–15° Linear Zoom |
| Color Temperatures | 3200K / 5600K / 8500K Adjustable |
| Color Rendering Index (CRI) | Ra ≥ 90 |
| Color Gel System | 5 Colors (Red, Orange, Yellow, Green, Blue) + Open White |
| Dimming | 0–100% Smooth Linear Dimming |
| Iris & Shutter | Precision Manual Iris Diaphragm & Blackout Shutter |
| Cooling Architecture | 16 x 8mm Copper Heat Pipes + Aluminum Radiator + Silent Fans |
| Control Protocol | DMX512 & Onboard Manual Operator Controls |
| Housing | Full Aviation Aluminum Alloy Body |
| Fixture Dimensions | 1020 x 400 x 450 mm |
| Fixture Weight | 22 kg (Stand Weight: 4.3 kg) |
CE & RoHS Certified
Complies with international electrical safety, harmonic suppression, and environmental standards.
Universal DMX512-A
Standard 3-pin / 5-pin XLR connectors, Art-Net/sACN compatible, with optoisolated data inputs.
Rigging & Flightcase
Supplied with safety wire loops, Omega quick-lock clamps, and touring-grade dual road cases on request.
Pan-India Support
Spare parts stock (ballasts, LED chips, power supplies, stepper motors) maintained across 20+ hubs.
