Profile SpotlightSKU: AI-CHROMA-SQUARE-200In Production
AI CHROMA SQUARE - 200 200W LED Square Face Profile Light
Architectural and theatrical 200W LED square luminaire with stepless focus adjustment, arbitrary variable projection aperture size, high-uniformity beam field, and precision DMX512 control.
Key Highlights
Light Source200W High-Efficiency COB LED
Total Power Consumption200W
Input VoltageAC 90V–240V, 50/60Hz
Color Temperature3200K / 5600K
Aperture AdjustmentStepless Focus with Arbitrary Variable Aperture Size
Control ModesDMX512, Auto-Propelled, Master-Slave
📞
Chat on WhatsApp›Factory Helpline+91 90150 60000
COMMERCIAL PROCUREMENT
Factory DirectRequest Official Quotation
ENGINEERING DATASHEET
Technical Specifications & Parameters
Full electrical, optical, thermal, and photometric characteristics for lighting designers, venue consultants, and electrical contractors.
| Parameter / Specification | Technical Value / Rating |
|---|---|
| Light Source | 200W High-Efficiency COB LED |
| Total Power Consumption | 200W |
| Input Voltage | AC 90V–240V, 50/60Hz |
| Color Temperature | 3200K / 5600K |
| Aperture Adjustment | Stepless Focus with Arbitrary Variable Aperture Size |
| Control Modes | DMX512, Auto-Propelled, Master-Slave |
| Dimming | 0–100% Linear Dimming |
| Cooling | Heavy-Duty Aluminum Profile with Silent Active Cooling |
| Motherboard / Power | XF Motherboard, HS High-Stability Power Supply |
| Display | Digital LED Menu Display with 4 Buttons |
| Ingress Protection | IP20 |
CE & RoHS Certified
Complies with international electrical safety, harmonic suppression, and environmental standards.
Universal DMX512-A
Standard 3-pin / 5-pin XLR connectors, Art-Net/sACN compatible, with optoisolated data inputs.
Rigging & Flightcase
Supplied with safety wire loops, Omega quick-lock clamps, and touring-grade dual road cases on request.
Pan-India Support
Spare parts stock (ballasts, LED chips, power supplies, stepper motors) maintained across 20+ hubs.
