Moving Head BeamSKU: AI-BEAM-BLAST-1440In Production
AI BEAM BLAST 1440-LED Multi-Color Pixel Beam Bar Light
1-meter high-density pixel beam bar featuring 1440 multi-color LEDs across 32 individually addressable RGBY & White zones, fanless silent heat sink, and up to 163 DMX channels.
Key Highlights
Light Source1440 LEDs (R288, G288, B288, Y288 @ 0.5W + W288 @ 1W)
Total Power300W Continuous (450W Max Strobe Burst)
Input VoltageAC 100V-240V, 50/60Hz
Beam SpreadRGBY 150° / White 120°
Independent Zones32 RGBY Zones + 32 Pure White Zones
DMX Channel Modes7, 8, 10, 15, 20, 83, and 163 Channels
📞
Chat on WhatsApp›Factory Helpline+91 90150 60000
COMMERCIAL PROCUREMENT
Factory DirectRequest Official Quotation
ENGINEERING DATASHEET
Technical Specifications & Parameters
Full electrical, optical, thermal, and photometric characteristics for lighting designers, venue consultants, and electrical contractors.
| Parameter / Specification | Technical Value / Rating |
|---|---|
| Light Source | 1440 LEDs (R288, G288, B288, Y288 @ 0.5W + W288 @ 1W) |
| Total Power | 300W Continuous (450W Max Strobe Burst) |
| Input Voltage | AC 100V-240V, 50/60Hz |
| Beam Spread | RGBY 150° / White 120° |
| Independent Zones | 32 RGBY Zones + 32 Pure White Zones |
| DMX Channel Modes | 7, 8, 10, 15, 20, 83, and 163 Channels |
| Dimming & Atomization | 0–100% Linear Dimming & Electronic Atomization |
| Cooling Technology | Fanless & Noiseless High-Conductivity Aluminum Extrusion |
| Control Protocols | Standard USITT DMX512 with Cable Firmware Upgrades |
| Display | High-Definition LCD Display (Multi-Language) |
| Protection Rating | IP20 |
| Dimensions (L x W x H) | 1000 x 96 x 150 mm |
| Net Weight | 7.5 kg |
CE & RoHS Certified
Complies with international electrical safety, harmonic suppression, and environmental standards.
Universal DMX512-A
Standard 3-pin / 5-pin XLR connectors, Art-Net/sACN compatible, with optoisolated data inputs.
Rigging & Flightcase
Supplied with safety wire loops, Omega quick-lock clamps, and touring-grade dual road cases on request.
Pan-India Support
Spare parts stock (ballasts, LED chips, power supplies, stepper motors) maintained across 20+ hubs.
